N Female-340, Male-341, DC-18 Ghz
N Female-340, Male-341, DC-18 Ghz
❮
❯
Specifications:
Impedance= 50 ohms
Frequency= DC-18 Ghz
VSWR DC-18 Ghz= 1.15:1 max
Contact Resistance: Center pin < 1.0 mohms
Contact Resistance: Housing < 0.2 mohms
Insulation Resistance > 5000 Mohms
Dielectric Withstanding Voltage > 1500 V
Durability: 500 cycles
Temperature Range= -55 C - +165 C
Interfaces: PER MIL-STD 348A
Material / Finish:
Housing: Stainless Steel SU303 Polished / Passivated
Center Condact: Beryllium Copper Gold plated (MIL-G-45204)
Insulators: PTFE & PEI
